CTM CT-10H 10000 BTU Marine Air Conditioner 230V

Overview CTM CT-10H 10000 BTU Marine Air Conditioner 230V

CTM CT-10H 10000 BTU Marine Air Conditioner 230V is a self-contained marine air conditioner and heat pump designed for 208-230V, 50/60Hz operation. This 10,000 BTU model is built for buyers who need higher-capacity marine climate control on a 230V electrical setup, while also keeping corrosion-resistant construction details such as titanium circulating coils, stainless steel bolts, and a stainless steel structural pan with an ABS tray.

The CT-10H is also presented as a drop-in replacement for major marine A/C brands including Dometic, Webasto, Cruisair, Marine Air, and Mermaid Air. The provided product information also states compatibility with Dometic, Cruisair, Marine Air, and Micro Air controls, thermostats, and cables, which may help simplify retrofit projects where compatible onboard control components are already in place.

Key Features of CTM CT-10H 10000 BTU Marine Air Conditioner 230V

- 10,000 BTU capacity for marine applications that need more output than smaller units.
- 208-230V, 50-60Hz operation for boats using higher-voltage onboard electrical systems.
- Self-contained marine air conditioner and heat pump configuration stated in the product data.
- High-velocity rotatable turbo blower supports onboard airflow, with rotation listed as less than 250 degrees.
- 347 CFM blower airflow and 1200 RPM blower speed provide clear model-specific performance details.
- Titanium circulating coils are specified for corrosion-resistant seawater cooling performance.
- Stainless steel bolts and structural pan help resist rust in demanding marine environments.
- ABS tray adds a durable, corrosion-resistant base component.
- Compatible with several major marine A/C control, thermostat, and cable platforms named in the product data.
- Backed by a 2-year warranty.

Applications

This model is suited to buyers looking for a 10,000 BTU marine A/C unit for a new installation or replacement project on a 230V electrical system. It can be a practical choice when a higher-capacity self-contained unit is needed and the installation benefits from compatibility with existing marine A/C controls and cables.

Because the product data identifies it as both an air conditioner and heat pump, this unit may also appeal to owners who want one onboard system that can support cooling and heating functions. Its higher-voltage specification makes it distinct from 115V versions in the same CTM range.

Why Choose This Marine Air Conditioner

The CTM CT-10H gives buyers a clearly defined 10,000 BTU, 230V option in the CTM lineup, making it easier to match capacity and electrical requirements correctly. Its buying value comes from the combination of confirmed heat pump functionality, self-contained design, corrosion-resistant materials, and compatibility with several widely used marine A/C control systems. For buyers comparing exact specifications, this model also provides clear figures including 3.3 A / 3.9 A input, 12 A starting amps, 22 A locked rotor amps, 347 CFM airflow, and a 2-year warranty.
