CTM CT-6HS 6000 BTU Marine Air Conditioner 230V

Overview CTM CT-6HS 6000 BTU Marine Air Conditioner 230V

CTM CT-6HS 6000 BTU Marine Air Conditioner 230V is a self-contained marine air conditioner built for 208-230V, 50/60Hz operation and equipped with soft start technology to reduce startup current demand. This version combines a compact 6,000 BTU platform with marine-ready construction details including titanium circulating coils, stainless steel bolts, and a stainless steel structural pan with an ABS tray.

For replacement projects, the CT-6HS is described as a drop-in option for major marine A/C brands including Dometic, Webasto, Cruisair, Marine Air, and Mermaid Air. The provided product data also states compatibility with Dometic, Cruisair, Marine Air, and Micro Air controls, thermostats, and cables, which may help buyers keep existing control components in place during an upgrade.

Key Features of CTM CT-6HS 6000 BTU Marine Air Conditioner 230V

- 6,000 BTU capacity for compact marine air conditioning installations.
- 208-230V, 50-60Hz operation for boats using higher-voltage onboard power systems.
- Soft start board uses a 4-part self-optimizing ramp sequence to lower startup current.
- Soft start is described as capable of reducing startup current by 65-75% compared with locked-rotor amperage.
- Listed starting amps are 7 A, supporting this model’s lower startup demand profile.
- High-velocity rotatable turbo blower delivers 282 CFM airflow, with rotation stated as less than 250 degrees.
- Titanium circulating coils are specified for corrosion-resistant seawater cooling performance.
- Stainless steel bolts and structural pan help resist rust in demanding marine environments.
- Compatible with several major marine A/C control, thermostat, and cable platforms named in the product data.
- Backed by a 2-year warranty.

Applications

This model is suited to buyers who need a 230V marine air conditioner for a compact installation or replacement project and want reduced startup current as part of the setup. It may be especially relevant where the boat relies on a generator, inverter, or limited utility power and startup load needs to be managed more carefully.

The provided product information also positions it as a practical option for replacement work where compatible controls, thermostats, and cables may already be onboard. For buyers comparing close variants, the soft start feature is the main differentiator of this exact model.

Why Choose This Marine Air Conditioner

The CTM CT-6HS is the 230V soft start version of CTM’s 6,000 BTU marine A/C platform, giving buyers a model that combines higher-voltage compatibility with reduced startup current. That makes it distinct from both the standard CT-6H and the 115V soft start version. Along with soft start, this model keeps the key verified features buyers often look for in a marine unit: titanium coils, stainless steel structural components, a turbo blower, control compatibility across several major platforms, and a 2-year warranty. For customers who need exact electrical fit and lower startup demand, this variant presents the clearest match in the range.
